Preface
The demand for lighting and display technologies is driving research to diversify the forms of devices. Future lighting and displays should be bendable, foldable, and stretchable to satisfy consumers’ desire for convenience and efficient use of space. Flexible components of lighting and display devices should be mechanically tolerant of repeated severe flexion. However, conventional light-emitting diodes (LEDs) for lighting and displays are mostly fabricated on a brittle transparent conducting oxide electrode (e.g., indium tin oxide [ITO]), which has poor tolerance to mechanical strain. Therefore, alternative flexible transparent conducting materials have been evaluated to replace ITO.
Graphene is a two-dimensional single-atom-thick sheet of carbon atoms in an sp2-bonded hexagonal configuration. Graphene’s unique structure yields excellent electrical and optical properties as well as mechanical robustness, so it is regarded as a strong candidate for use as a flexible electrode in lighting and displays. However, pristine graphene has several characteristics that limit its practical applications in flexible self-emissive LEDs. Its sheet resistance Rs is too high, and its work function (WF) is too low for graphene to be effective as an anode in LEDs. Chemical doping of graphene can control Rs and WF, so the charge injection from graphene electrode to overlying layers in LEDs can be significantly improved. As a result of appropriate chemical doping, especially with organic and polymeric dopants, the luminous properties of organic light-emitting diodes (OLEDs) based on graphene electrodes have been increased to be comparable to those of OLEDs that use ITO electrodes. The doping can also make graphene very stable against moisture, organic solvents, and acids.
Graphene-based materials can be used as an interfacial layer to improve the charge injection in LEDs. Pristine graphene has no bandgap, but chemical functionalization (e.g., oxidation, hydrogenation) can induce one and provide an intermediate step for charge injection, so the luminous properties of LEDs can be improved. Graphene quantum dots (QDs) can also themselves be light emitters. The graphene QDs have advantages (e.g., nontoxicity, high chemical stability, high carrier mobility) over inorganic QDs.
Graphene can also be stretchable, so it can be used in stretchable electronics and displays. To date, several structural modifications or composite with other stretchable conducting materials have increased the stretchability of graphene and allowed it to be used in stretchable electronics.
This book will cover the fundamental electrical, optical, and mechanical properties of graphene; the preparation of pristine graphene, doped graphene, graphene-derived interfacial and graphene QD emitting materials and their composites; and treatments to modify its electrical properties by adsorbed molecules and deposited films. Then the book presents the use of flexible or stretchable electrodes with graphene or its composites in various LEDs for lighting and displays (e.g., OLEDs, inorganic LEDs, QD-LEDs, and halide perovskite LEDs). It will also describe the use of graphenederived materials as interfacial buffer layers or as light-emitting layers in LEDs.
This book is written by leading experts who are working on graphene-based materials and optoelectronic devices. It provides in-depth information on use of graphene in light-emitting devices. The overall goal of this book is to provide comprehensive information about fundamental properties of graphene; on methods to synthesize graphene; on techniques to prepare graphene electrodes and composite electrodes; on methods to dope graphene electrodes; and on applications of graphene-based flexible electrodes, interfacial buffer layers, nanoscale emitters, and graphene-based stretchable electrodes. The ultimate objective is to inspire further research on practical optoelectronics applications of graphene.
This book will be of interest to the large community of researchers who are working on applying graphene in various electronic and optoelectronic devices and may stimulate research to develop practical uses of graphene sheets in next-generation displays and lightings. The book will additionally provide future prospects and suggest further directions for research on graphene-based next-generation displays and lightings. Therefore, this book will be helpful for students, professors, researchers, and engineers who work on graphene or graphene-derived materials or on graphene-based displays and lighting technology.
